Chicago Pneumatic CP2755 & CP2765 Screwdrivers

Category:



1/4″ Hex direct drive pneumatic screwdrivers



Standard lead time may apply

Chicago Pneumatic CP2755 & CP2765 Screwdrivers



The Chicago Pneumatic CP2755 & CP2765 Screwdrivers are 1/4″ hex quick change pistol direct drive screwdrivers designed for fastening operations. Progressive trigger and reverse control at the trigger ensure high level of operator control. Ideal for soft-pull applications in wood and other soft materials. Available in 2 torque level models.



Features

  • Direct drive pistol screwdriver
  • 1/4″ Hexagonal Quick change
  • Reverse control at the trigger
  • Rubber grip
  • Progressive trigger



Benefits

  • Fast screw rundown in direct drive for better productivity
  • Reverse control at the trigger for better comfort
  • Rubber grip for better handling
  • Progressive trigger for better ergonomics





Download CP multilingual Safety Instructions & Safety Data Sheets button      Similar products with i button

Additional information

Model

CP2755, CP2765

Actual air consumption

283 l/mn

Air inlet thread size

1/4 "

Average air consumption

71 l/mn

Bit holder

Quick Change Hexagonal Female

Clutch type

Direct drive

Diameter

21 mm

Free speed

2200 rpm, 900 rpm

Free speed air consumption

14 l/s

Handle type

Pistol

Height

149 mm

Length

160 mm, 178 mm

Max working torque

7.3 Nm, 9 Nm

Min. hose size

10 mm

Net weight

1.03 kg, 1.18 kg

Output drive

1/4 inches

Sound Power

101 db(A), 110 db(A)

Sound pressure

90 db(A), 99 db(A)

Vibration

<2.5 m/s²

Vibration ISO

ISO-28927-2

Vibration uncertainty (K)

– m/s²
